Ados T060E - Configuring T060 E Serial Port 1 Function; Configuring T060 E Serial Port 2 Function; Setting T060 E Serial Port 1 Physical Interface

1569‐PT060EE1 Rev.7 Page34of62
5.4.16 Function of serial port 1
S E R 1
S E R I A L
IncaseofPROFIBUSoption

OFF
Serialportexcluded.
CON
Serialportwithconstantstringtransmission.
BIDIR
Serialport withlogic HALFDUPLEXprotocol.The instrumentrespondsas
slave. In case of  multi‐point operating mode, the data structure foresees
theadditionalIDRS485addressfield.

MODBUS
SerialportenabledtoMODBUS‐RTUprotocol

5.4.17 Function of serial port 2 (excluded in case of PROFIBUS option)
S E R 2

OFF
Serialportexcluded.
CON
Serialportwithcontinuosstringtransmission.
BIDIR
SerialportwithlogicHALFDUPLEXprotocol.Theinstrumentrespondsas
slave.Incaseofmulti‐pointoperatingmode,thedatastructureforesees
theadditionalIDRS485addressfield.

REPEAT
ItforeseestheinterfacingwithADOSrepeaters.

5.4.18 Physical interface of serial port 1
L I N E 1
L I N E
IncaseofT060EwithPROFIBUSinterface.

RS-485
PhysicalinterfaceRS485ontwobalancedwires
RS-232
PhysicalinterfaceRS232(point‐pointconnections)


