5.4.2 Editing of the value of operational parameters
Byaccessingtheconfigurationmodefromtheparameterselectionmenu,theinstrumentshowstheparameter'svalue
orcodeonthemaindisplay.
Thedisplayflashestoindicatethattheinstrumentisreadytoaccepttheeditedparameter’svalue.
Press key to increase the value of the selected parameter (once
the maximum value is reached, the
systemreturnsautomaticallyto0).
Ifthedatashownisaweight(e.g.arelaythreshold),theincreasetakesplaceaccordingtotheconfiguredsensitivity.
By keeping key pressed, the increase gradient is automatically increased up to maximum 128 times the
basicincreasevalue.
Press
key to decrease the value of the selected parameter (once zero is reached, the system returns
automaticallytothemaximumvalue).
Ifthedatashownisaweight(e.g.arelaythreshold),thedecreasetakesplaceaccordingtotheconfiguredsensitivity.
Bykeeping key pressed,the decreasegradient isautomatically
increasedup to maximum 128times the
basicdecreasevalue.
Presstocanceltheconfigurationrequestandreturntotheselectionmenuofthenextparameter.
Presskey toconfirmthechange.
Theinstrumentchecksifthesetvalueisacceptableanddisplaysthefollowingmessagefor2seconds:
D O N
andthenitautomaticallyreturnstotheparameter’sselectionmenu.
