5.4.7 Reference channe selection (only with instrument with double channel)

P R I O R
Thisparameterdefinethereferencechannel

CH 1
CH 2
5.4.8 Scale factor selection ((only with instrument with double channel)

M U L T I P
Thisparameterdefinethescalefactorselection.

OFF
M 10
Valuemultiplyingfor10
M 100
Valuemultiplyingfor100
M 1000
Valuemultiplyingfor1000
M 10000
Valuemultiplyingfor10000
D 10000
Valuedividingfor10000
D 1000
Valuedividingfor1000
D 100
Valuedividingfor100
D 10
Valuedividingfor10
5.4.9 Relay 1 function
F U N R 1
Thisparameterdefinesthefunctiontoassigntorelay1.See
chapter2.5.


FAIL 1
LO N1
HI N1
LO G1
HI G1
TOT N
TOT G
ON
