Ados T060E - T060 E MODBUS Protocol Communication

1569‐PT060EE1 Rev.7 Page55of62
6.4 Bi-directional modality with MODBUS protocol
TheRTUversionofMODBUSisused.

Receivedandtransmittedframestructure.
Generalframestructureisasfollows:

ADRESS FUNCTION DATA CHECK
8bits 8bits Nx8bits 2x8bits
ADDRESS FUNCTION DATA CHECK
8bits 8bits Nx8bits 2x8bits

ADDRESS 8bitdefiningtheslaveaddressandrangingfrom1to32
FUNCTION 8bitdefiningtherequiredfunction.
ThefunctionssupportedbyT060Earethefollowing
Code03ReadHoldingRegisters
Code05ForceSingleCoil
DATA Alldatarelevanttothespecificfunction
CHECK CRC‐16
(CyclicRedundancyCheck)framevalidation

Exceptionresponses

WhenT060Ereceivesarequestinvolvingillegalfunctionsorillegaldataanexceptionresponseisgeneratedcontaining
address,functioncode,errorcodeandchecksum.
Toindicatethattheresponseisanotificationofanerror,thehighorderbitofthefunction
codeissetto“1”.

Supportederrorcodeare:
 01 Illegalfunction.Themessagefunctionreceivedisnotanallowableactionforthe
addressedslave.
 02 Illegaldataaddress.Theaddressreferencedinthedatafieldisnotanallowable
addressintheaddressslavelocation
 03 Illegal
datavalue.Thevaluereferencedinthedatafieldisnotallowableinthe
addressedslavelocation

T060Esupportedfunctions

ForacompletedescriptionofMODBUSavailablefunctions,pleaserefertodetailedMODBUSdocumentation.

Function03‐ReadHoldingRegisters

Allowsthehosttoobtainthebinaryvalueof
thecontentofT060Eregisters

Allregisterscanbetransferredinasinglereadrequest.

Thebelowexamplereadsregisters0through2fromslave01:
ADDR FUNC START
REGHI
START
ERG
LOW
#OF
ERGHI
#OF
ERG
LOW
CHECK
01 03 00 00 00 03 05CB

Slaveanswerisasfollows:
ADDR FUNC BYTE
COUNT
REG
0
HI
REG
0
LOW
REG
1
HI
REG
1
LOW
REG
2
HI
REG
2
LOW
CHECK
01 03 06 00 0F 00 00 01 C0 74B4

Valueofregister0is15,register1is0andregister2is448.

