1569‐PT060EE1 Rev.7 Page37of62
5.4.25 PROFIBUS address (only in case of PROFIBUS option)
D P A D D
ItallowsidentifyingthePROFIBUSaddress(from1to127).

5.4.26 Analogue output
Theconfigurationoftheanalogueoutputforesees3steps:
AN NOD
Definitionofthetypeofoutputrequired.
AN VAL
Definitionoftheoperatingmodeoftheanalogueoutput.
AN FS
Definitionofthefullscaletoassociatetotheanalogueoutput.

5.4.27 Definition of the type of analogue output
A N N O D


A 4-20
Outputunder4‐20mAcurrent.
A 0-20
Outputunder0‐20mAcurrent.
U 0-10
Outputunder0‐10Vvoltage.
U10-10
Outputunder10‐10Vvoltage.

5.4.28 Function of the analogue output
A N V A L


NET 1
Thevalueof theanalogueoutput isproportionaltothenet weightvalue
(displayedvalue)ofchannel1.
GROS 1
Thevalueoftheanalogueoutputisproportionaltothegrossweightvalue
(valueindependentfromtheresetvalue)ofchannel1.

NET 2
Thevalueof theanalogueoutput isproportionaltothenet weightvalue
(displayedvalue)ofchannel2.
GROS 2
Thevalueoftheanalogueoutputisproportionaltothegrossweightvalue
(valueindependentfromtheresetvalue)ofchannel2.

TOT N
Thevalueoftheanalogueoutputisproportionaltothegrossweightvalue
(valueindependent from the reset value),which is the sumof channel 1
andchannel2values.
TON G
Thevalueof theanalogueoutput isproportionaltothenet weightvalue
(displayedvalue),whichisthesumofchannel1andchannel2values.
Thechangeoftheanaloguefunctioncausetheclearanceoftheanalogoutputdata(ANFS).
