1569‐PT060EE1 Rev.7 Page57of62

6.4.2 Status word coding

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
IN2 IN1 SR R5 R4 R3 R2 R1 UL2 OL2 FAIL2 UL1 OL1 FAIL1 S POF

POFPowerOnFlag.Indicatesareturnofpowersupplytothetransmitter
Flagissetto1byT060Eandcanberesettedto0byhostbyforcingCoil#0
SIf=1indicatesconfigurationinprogressorintest
R1If=1indicatesthatthe
relay#1isenergized
R2If=1indicatesthattherelay#2isenergized
R3If=1indicatesthattherelay#3isenergized
R4If=1indicatesthattherelay#4isenergized
R5If=1indicatesthattherelay#5isenergized
SRIf
=1indicatesthattherelay#SRisenergized
FAIL1If=1indicateschannel1inFAIL
OL1If=1indicateschannel1inOL
UL1If=1indicateschannel1inUL
FAIL2If=1indicateschannel2inFAIL
OL2If=1indicateschannel
2inOL
UL2If=1indicateschannel2inUL
IN1If=1indicatestheclosingofdigitalinput1.
IN2If=1indicatestheclosingofdigitalinput2.



6.4.3 List of Colis supported by T060E
No.Coil Funzione
0 PowerOnFlag resetrequest
1 Tarechannel1request
2 Tarechannel2request
3 Tareresetchannel1
4 Tareresetchannel2


