1569‐PT060EE1 Rev.7 Page29of62
5.4 Configuration of operational parameters
5.4.1 Selection of operational parameters
By accessing the configuration mode from the selection menu of configuration levels, the instrument is ready to
configure the first parameter and displays the following message:
S E G N 1
Press key to select all configurable parameters in sequence (once the last one is reached, the system
returnstothefirstoneautomatically).
Presskey toselectallconfigurableparametersinsequence,inreverseorder(oncethefirstoneisreached,
thesystemreturnstothelastoneautomatically).
Presskeytocanceltheconfigurationrequestandreturntotheselectionmenuofconfigurationlevels.
Press key to confirm the selection, the instrument is ready to configure the selected parameter: the
display shows the parameter’s value or code and, with a frequency of half second for every two seconds,
the
parameter’scodeonwhichyouareoperating.
Thesettings/considerationsmadeforchannel1alsoapplyforchannel2.
