4-70 ADS TRITON+
®
Manual
z Pipe Height This field displays the pipe height at the monitor
location, based on the installation table. This parameter is not
editable from this location.
Note: Under normal conditions, the remaining
parameters corresponding to the Surface Combo device
should not require modification. However, if additional
adjustments are necessary, the following sections provide
a detailed description of each parameter.
Smart Depth (Ultrasonic) tab – ParaFlow/Surface
Combo
The Smart Depth sensor measures the distance (or range) from the
crown of the pipe to the surface of the flow.
Edit the following parameters corresponding to the downward-
looking ultrasonic (smart) depth sensor in the ParaFlow and Surface
Combo Sensors:
z Electronic Offset Enter the difference that exists between
the smart depth sensor readings and the manually measured
depth, when applicable. The default value is 0.
Note: An electronic offset is rarely needed. An offset
greater than +/- 0.5 inches (13 mm) typically indicates that
the physical offset or pipe height has been measured or
recorded incorrectly.
z Mode Select the mode in which you want the smart depth
sensor to operate based on environmental factors or site
constraints. The default setting is Normal power. However, if
erratic Smart Depth readings occur, consider changing the
Power setting to High power.
Note: The ParaFlow sensor can use the Normal setting
across its full sensor range in most installations. In rare
instances if the flow is quite choppy or has foam, the High
setting may be better.
