External Power 6-25
Inserting the 18-gauge ground wire into the top terminal of one of the ground
terminal blocks
2. Loosen the terminal screw corresponding to the bottom
terminal of one of the ground terminal blocks next to the
ExPAC, and insert one end of the 12-gauge ground wire into
the terminal and tighten the screw.
DC Input Terminal
ExPAC
Ground Terminal Blocks
18 Gauge GND Wire
