11-10 ADS TRITON+ Manual
Check the current battery voltage in the monitor through Qstart
XML
in the following way:
Note: Checking the battery voltage through the monitor
status in Qstart
XML
for monitors equipped with dynamic
SIM cards is possible only through a serial (direct)
connection.
1. Select the monitor for which you want to check the battery
voltage form the Location Name field in the Monitor section
on the ADS Qstart
XML
dialog.
2. Click on the Status button in the Functions section.
Once communication is established, the Monitor Status
window displays the current status information for the monitor,
including the current battery voltage. The status bar on the
ADS Qstart
XML
dialog also displays the current battery
voltage. Qstart
XML
will display the battery voltage on the
status bar in red if it is low.
3. Review the Monitor Status that displays once communication
has been established. Replace the battery pack when the
Monitor Status indicates that the internal voltage is low.
The Print Preview dialog displays the current system
information, including the monitor battery voltage, in printable
format. Select the Print button to print the report contents, if
desired.
