Hybrid Standalone NVR User Guide 3 Local Menu Operations
3.6.2.3 Tour Tab
Here you can activate the Tour function, which presents an alternating display (much like a
slideshow) of the channel(s) you have set to record when a motion detection or alarm event occurs.
Figure 3-58
Motion Tour Type. Select from the dropdown the motion tour combination set up in the Window Split
screen below.
Alarm Tour Type. Select from the dropdown the alarm tour combination set up in the Window Split
screen below.
Enable Tour. Check the box to enable this function.
Interval. The system supports 1/4/8/9-window tour. Input the desired interval value here for the
scheduled tour/motion detection tour. The value ranges from 5-120 seconds.
Window Split. Select the window split mode from the dropdown list.
Channel Combination. This area is for viewing channel names under current window split mode.
You can add/delete channels here. Double-click an item to edit the channel group. The system
supports a maximum of 16 channels.
• Add. Under the specified window split mode, click to add a channel group.
• Delete. Click to remove the selected channel group.
• Move up. Click to move the currently selected channel up.
• Move down. Click to move the currently selected channel down.
• Default. Click to restore the default setup.
After completing the settings, click the Save button. The system returns to the previous menu.
Tip: On the navigation bar, click / to enable/disable Tour. Click Save to save the current setup.
