Hybrid Standalone NVR User Guide 3 Local Menu Operations
To use the FTP feature:
1. Highlight the Enable box to activate the FTP function.
2. Input the FTP server address, port and remote directory. When a remote directory is not
available, the system automatically creates folders according to the IP, time and channel.
3. Enter the User Name and Password as the account information for you to login the FTP.
4. Set upload file length, picture upload interval, upload file channel, time and type.
• File length is upload file length. When this value is larger than the actual file length, the
system will upload the whole file. When this value here is smaller than the actual file
length, the system only uploads the set length and automatically ignores the left section.
When the interval value is 0, the system uploads all corresponding files.
• At the same time, you can set two periods and three recording files for different channels.
5. Click the Test button. The corresponding dialog box appears to show that the FTP
connection is OK.
3.3.10 SNMP
SNMP is an abbreviation of Simple Network Management Protocol. It provides the basic network
management framework of the network management system. SNMP is widely used in many
environments, network devices, software and systems.
Figure 3-24
Enable the SNMP function. Use the corresponding software tool (MIB Builder and MG-SOFT MIB
Browser. You will need two MIB files: BASE-SNMP-MIB, NVR-SNMP-MIB) to connect to the device.
You can get the device’s corresponding configuration information after a successful connection.
NVR4200 Series User Guide
54
