Hybrid Standalone NVR User Guide 4 Web Service
4.5 Playback (Search)
This section describes how to search for a recorded file and then view it.
1. Click the Playback Tab button. The screen shown in Figure 4-6 appears.
2. Set the record type, record date, window display mode and channel name.
3. Click the date on the right pane to select the date.
The amber highlighted date is the current system date and the blue highlighted date on the
calendar indicates that there are recorded files for that date.
Figure 4-6
4. Click the File List button. The corresponding files in the list appear, as shown in Figure 4-7.
5. Select the file you want to play and then click the Play button .
The system begins playback. You can select to playback in full screen. Note that for one
channel, the system cannot playback and download at the same time. The recording is
automatically saved at the Download folder of the installation directory.
NVR4200 Series User Guide
131
