Hybrid Standalone NVR User Guide 4 Web Service
Display Filter
Click the dropdown to filter the specified devices displayed in the added device.
Added Device field
• Modify: Click the button or double click a device in the list to change the channel setup.
• Delete: Select one device in the Added Device list and then click to remove.
• Status: means the connection is OK and means the connection failed.
Delete button
If you select a device on the Added Device list, and then click the Delete button, the device is
disconnected and then its name is removed from the list.
Manual Add button
Click to add the network camera manually. The port number is 37777. The default user name is
admin and password is admin.
Figure 4-12
Channel: The dropdown list here displays unconnected channel number. Set the remote channel
connection in the main dialog.
Note:
• This NVR supports the IPC from many popular manufacturers such as Sony, Hitachi, Axis,
Samsung, Dynacolor, Arecont, Onvif and Dahua.
• The system default IP address is 192.168.0.0. If you do not input an IP address, the system
will not add the current IP address.
• You cannot add more than one device at a time using the Manual Add feature.
NVR4200 Series User Guide
137
