Hybrid Standalone NVR User Guide 4 Web Service
• FTP Server IP number
• Port number
• User Name and Password you use to log into the FTP.
• Optionally check the Anonymous box for servers that support the anonymity function,
which allows you to automatically login anonymously. If enabled, you do not need to
input the user name, password or the sender information.
3. Enter the Remote Directory.
4. Enter the upload File Length.
File length is upload file length. When this value is larger than the actual file length, the
system uploads the whole file. When this value is smaller than the actual file length, the
system only uploads the set length and automatically ignores the left section. When interval
value is 0, system uploads all corresponding files.
5. Set the Image Upload Interval.
6. Use the drop-down menu to select the upload file Channel.
7. Use the drop-down menu to select the day.
8. Set the Time Period and type of event: Alarm, MD (motion detection) or Regular.
9. Click Save.
4.7.4.3 Record Control
This feature enables you to manually override the automatic record settings.
Figure 4-76
There are two modes of operation: Main Stream and Extra Stream; and three status settings for each
mode: Schedule, Manual and Stop.
Schedule
Channel records as you have set in recording setup (Main Menu > Setting > Schedule)
NVR4200 Series User Guide
190
