2 Getting Started
Using the USB Mouse:
1. Use the USB mouse to select the User Name from the Drop-down menu.
2. Click in the Password field. The virtual keyboard appears.
Figure 2-3
3. Toggle the ABC/ abc button or Shift key to select between upper or lower case letters.
Note: Because the numeric pad appears on both upper case and lower case virtual keyboards, you
do not need to change keyboards to make numeric entries.
4. Select the desired alpha/numeric character. It turns green and enters the Password field.
5. Repeat until all characters are entered.
6. Click Enter on the virtual keyboard. The keyboard disappears.
7. Click OK on the System Login dialog to enter.
Using the Remote Control:
1. Press Enter. The SYSTEM LOGIN dialog appears. Press Esc to remove the dialog.
2. The User Name field is highlighted in light blue. Use the and arrow keys to select the
desired user name.
3. Use ►arrow key to shift to the Password field. It is highlighted in light blue.
4. Press the Shift key to toggle between upper case letters, lower case letters or numeric input.
5. Use the keypad on the remote to enter the desired characters.
6. Press the Enter key on the remote. The keyboard disappears.
Using the Front Panel:
1. Press Enter. The SYSTEM LOGIN dialog appears. Press Esc to remove the dialog.
2. The User Name field I highlighted in light blue. Use the and arrow keys to select the
desired user name.
3. Use ►arrow key to shift to the Password field. It is highlighted in light blue.
4. Press the Shift key to toggle between upper case letters, lower case letters or numeric input.
5. Use the numeric values on the various keys to enter the desired characters.
6. Press the Enter key. The keyboard disappears.
Note: For security reasons, modify your password after your first login.
• Three (3) sequential login failures will result in a system alarm
• Five (5) sequential failures will result in account lockout
NVR4200 Series User Guide
2
