Appendix B Specifications
Network
Ethernet RJ-45 port (10/100/1000Mbps)
PoE Ports 4 ports (IEEE802.3at) and 8 ports (IEEE802.3at)
HTTP, TCP/IP, IPv4/IPv6, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE,
DDNS, FTP, Alarm Server, IP Search (supports ADT IP cameras, DVR, NVS, etc.)
Max User Access 128 users
Smart Phone iPhone, iPad, Android
Storage
Internal HDD 2 SATA ports, up to 8TB
Auxiliary Interfaces
USB 2 ports (1 Rear USB3.0, 1 Front USB2.0)
RS232 1 port, for PC communications and Keyboard
RS485 1 port, for PTZ control
General
4 channel model: NVR:12VDC, 4A / PoE: 48VDC, 1.04A
8 channel model: NVR: 100 ~ 240VAC, 50/60 Hz
Power Consumption NVR: 20W (without HDD) / PoE: 25.5 W max for single port
Environment
14°F
131°F (–10°C
+55°C); 10%
90% RH
Dimensions (WxHxD)
1U: 14.76 x11.22 x1.97 in (375 x 285 x 50 mm)
4 channel model: 4.41 lb (2.0 kg) without HDD;
8 channel model: 5.5 lb (2.5kg) without HDD
NVR4200 Series User Guide
224
