Adtech CNC9640 User Manual

ADTECH9 Series CNC Maintenance Manual
- 194 -
5 IN4 B axis home
6 IN5 Standby input
7 IN6 Standby input
8 IN7 Standby input
9 IN8 Standby input
10 IN9 Standby input
11 IN10 Standby input
12 IN11 Standby input
13 IN12 Standby input
14 IN13 Standby input
15 IN14 B axis negative limit
16 IN15 B axis positive limit
17 IN16(XLMT-) X axis negative limit
18 IN17(XLMT+) X axis positive limit
19 IN18 Y axis negative limit
20 IN19 Y axis positive limit
21 IN20(ZLMT-) Z axis negative limit
22 IN21(ZLMT+) Z axis positive limit
23 IN22 A axis negative limit
24 IN23 A axis positive limit
25 INCOM
Input common end INCOM (24V+, 12V+) connects
to internal or external power supply
Default input port configuration of 99M series XS7 (CNC9960 milling machine)
The digital input interface including the home of every axis (X, Y, Z, A, B, C), the hardware limit signal of every
axis (X, Y, Z, A, B, C), and the definition is as follows:

Adtech CNC9640 Specifications

General

Brand	Adtech
Model	CNC9640
Category	Control Systems
Language	English
