ADTECH9 Series CNC Maintenance Manual
- 42 -
⑴ Insert the USB disk;
⑵ Select [Monitor], [File] in the menu to enter file operation interface;
⑶ Select USB disk and press [EOB] to enter;
⑷ Move cursor to select a file in the disk;
⑸Press [EOB] to load the file into work area (system buffer);
⑹ Press mode selection key [Auto];
⑺ Press the [Start] key to run the program, and the indicator is on.
0 Caution
The system won’t record the USD disk path. If power failure occurs during DNC processing, the program info
will be lost when the power supply is connected again.
4.4
Speed rate adjustment
Feeding rate
In automatic mode, press Up/Down key in [Position] interface to adjust the feeding rate; Press the key once to
increase or decrease by 10% (10%-150%).
Manual rate
In manual mode, press Up/Down key in [Position] interface to adjust the manual rate; Press the key to increase
or decrease by 10% (10%-150%). If you press the FF key and Up/Down key, you can adjust the fast forward rate
by 10% (10%-150%).
Spindle rotation
In automatic or manual mode, when the spindle rotates normally, press the Left/Right key to adjust the spindle
rotation by 100r/min. The maximum rotation is set by the spindle parameters in the system and the minimum
rotation is 16r/min. If you press and hold the key for three seconds, the value will be increased or decreased
quickly.
4.5
SBK function
In automatic mode, press [SBK] to start the SBK function. Current program block stops after executing; press
[Start] again and next block stops after executing. The SBK mode allows checking the program block by block.
0 Caution:
① In G28-G30, single block also can be stopped at the center point;
② The stop points of single block in fixed circle are ①, ②, ⑥ in the figure below; when the single blocks of
①, ② stops, the feeding pauses and the pause indicator is on.
