ADTECH9 Series CNC Maintenance Manual
- 37 -
3.14.2. Tool Regulator Parameter
Coordinates -> Tool setting parameters
15~20. The limit of tool regulator machine X, Z, A, B, C. Search for the maximum position of the axis when
searching for the tool regulator, and this value is the machine coordinate value. The search stops when the search
axis motion value is equal to or greater than the set value, and an alarm is given.
21. Searching direction of the tool regulator---------- Set the tool limit coordinate and the search direction of the
tool regulator. 1 is the negative direction searching, and 0 is the positive direction searching.
28. Scanning speed of the tool regulator----------Set the search speed when the system searches for the tool
regulator signal. The speed is defaulted as 1,000mm/min. For example, when the Z-axis starts searching for tool
regulator signal in negative direction, the tool regulator searches at the speed of 1,000 mm/min until the system
detects the tool regulator signal, and the system then switches to a low scanning speed to reposition the signal of
tool regulator.
38.
Way of tool setting ----------set the processing mode after the system tool regulator scanning setting is
finished: 1 is the tool setting mode when non-reference tool is used. After the scanning is finished, the system
will set the calculated workpiece origin position to the coordinate system, for example, the zero coordinate of
the workpiece after scanning is -90, the system will then set the coordinate value of -90 to the Z-axis in the
coordinate system (when the Z-axis is set), and the set coordinate system is the one currently selected in the
coordinate setting, the length compensation is realized by calling the coordinate system command in the
program. 0 is the tool setting method by taking No.1 tool as the reference tool. After the scanning is finished, the
compensation value is set to the length compensation in the allowance, for example, when the No.2 tools is
aligned, the system sets the tool value to the No.2 length compensation value of the allowance, and then calls
G43 H2 in the program to realize the length compensation. Taking No.1 tool as the reference tool means that,
when measuring the coordinate offset, the measurement is performed with No.1 tool, and the No.1 amount of
compensation in the allowance is generally zero.
When the tool setting mode is set to 3, the system will input the data of each tool measured by the tool regulator
in the tool compensation interface. Please note that the Z value is set to 0 in the coordinate system.
Coordinates->Allowance
Steps to use tool regulator and troubleshooting
1. According to the system requirements, after modifying the parameters, observe system diagnostic
screen to check whether the input signal is normal, and whether the effective level is correct. In the diagnostic
screen, for example, if the red lamp of IN5 lights up, it indicates that low level is detected as 0, and green lamp
