ADTECH9 Series CNC Maintenance Manual
- 28 -
Press [Centered Measurement] to enter centered interface;
Move the tool to make its side blade touch the surface of round workpiece, and press [EOB] to record
boundary point 1;
Move the tool to make its side blade touch another point in the surface of the workpiece, and press [EOB]
to record boundary point 2;
Move the tool to make its side blade touch another point in the surface of the workpiece, and press [EOB]
to record boundary point 3;
Press [EOB] after recording all boundary points to calculate the coordinates of circle center and display in
the result section;
If there is no question, press [EOB] again to return the result to specified coordinate system.
Arc centered validation
In the main menu, press [Monitor], [MDI] to enter the MDI interface, select edit mode, enter program block
G55G0X0Y0 (if coordinate system G55 is selected while tool setting), press [Start], [EOB], and the tool moves
to workpiece center automatically, indicating that three points arc centered properly.
The validation steps for other tool setting methods are same.
3.10.2. Tool regulator setting gauge (M series)
The tool regulator of CNC96xx system can realize Z-axis tool setting and A-axis tool setting, and can perform
the detection by using the same tool regulator. It can switch Z-axis tool setting or A-axis tool setting. The tool
regulator function is not enabled by default, so you need to modify the parameters before use. This document
description is based on the system version 7.0 or above.
Related parameters and instructions for using the system tool regulator:
1. Install the tool regulator (the figure below shows the wiring diagram of tool regulator of a brand).
