ADTECH9 Series CNC Maintenance Manual
- 62 -
8.1.2 Relative Position
In manual mode, reset current coordinates to check the relative motion distance of any displacement, and thus it
is called as relative position.
This interface is usually used for early tool setting. Considering that some operators have been used to manual
calculation, this function is preserved. With more and more powerful automatic centered function, it is less used.
The operation is as follows:
Enter [Position] interface;
Switch to [Relative] interface;
Then, enter manual mode;
Press a coordinate axis No., e.g., ‘X’, and the X coordinate flashes;
Press “Cancel” to reset X coordinate to 0;
The relative position interface is as follows:
Relative Position Interface
