ADTECH9 Series CNC Maintenance Manual
- 232 -
J2 GND 24V power supply output GND terminal
J2
External
Switch
IN20 IN20 #1020
J2 IN21 IN21 #1021
J2 IN22 IN22 #1022
J2 IN23 IN23 #1023
J2
POWER
+24V 24V power supply output terminal
J2 GND 24V power supply output GND terminal
J2
INPUT
24-27
IN24 IN24
J2 IN25 IN25
J2 IN26 IN26
J2 IN27 IN27
J2
POWER
+24V 24V power supply output terminal
J2 GND 24V power supply output GND terminal
J2
INPUT
28-31
IN28 IN28
J2 IN29 IN29
J2 IN30 IN30
J2 IN31 IN31
12.4. ET102A splitter wiring diagram
