ADTECH9 Series CNC Maintenance Manual
- 231 -
Termin
al No.
Area Port Name Standard System function
J2
POWER
+24V 24V power supply output terminal
J2 GND 24V power supply output GND terminal
J2
Ｘ, Ｙ
Axis Limit
X+ X+ axis limit IN00, 1000
J2 X- X- axis limit IN01, 1001
J2 Y+ Y+ axis limit IN02, #1002
J2 Y- Y- axis limit IN03, 1003
J2
POWER
+24V 24V power supply output terminal
J2 GND 24V power supply output GND terminal
J2
Z, A
Axis Limit
Z+ Z+ axis limit IN04, 1004
J2 Z- Z- axis limit IN05, #1005
J2 A+ A+ axis limit IN06, 1006
J2 A- A- axis limit IN07, 1007
J2
POWER
+24V 24V power supply output terminal
J2 GND 24V power supply output GND terminal
J2
B, C
Axis Limit
B+ B+ Axis Limit IN16, 1016
J2 B- B- axis limit IN17, 1017
J2 C+ C+ axis limit t IN18, 1018
J2 C- C- axis limit IN19, 1019
J2
POWER
+24V 24V power supply output terminal
J2 GND 24V power supply output GND terminal
J2
X, Y, Z, Z
Origin Switch
X X Origin IN08, 1008
J2 Y Y Origin IN09, 1008
J2 Z Z Origin IN10, 1010
J2 A A Origin IN11, 1011
J2
POWER
+24V 24V power supply output terminal
J2 GND 24V power supply output GND terminal
J2
B, C Origin
Switch
B B origin IN12, 1012
J2
C C origin IN13, 1013
J2
Press
IN14 7 origin IN14 #1014
J2 IN15 8 origin IN15 #1015
J2 POWER +24V 24V power supply output terminal
