Adtech CNC9640 User Manual

ADTECH9 Series CNC Maintenance Manual
- 218 -
Terminal
No.
Area Port Name Function
J2
POWER
+24V 24V power supply output terminal
J2 GND 24V power supply output GND terminal
J2
X, Y
Axis Limit
X+ X axis positive limit
J2 X- X axis negative limit
J2 Y+ Y axis positive limit
J2 Y- Y axis negative limit
J2
POWER
+24V 24V power supply output terminal
J2 GND 24V power supply output GND terminal
J2
Z, A
Axis Limit
Z+ Z axis positive limit
J2 Z- Z axis negative limit
J2 A+ A axis positive limit
J2 A- A axis negative limit
J2
POWER
+24V 24V power supply output terminal
J2 GND 24V power supply output GND terminal
J2
B, C
Axis Limit
B+ B axis positive limit
J2 B- B axis negative limit
J2 C+ C axis positive limit
J2 C- C axis negative limit
J2
POWER
+24V 24V power supply output terminal
J2 GND 24V power supply output GND terminal
J2
X, Y, Z, Z
Origin Switch
X X Origin
J2 Y Y Origin
J2 Z Z Origin
J2 A A Origin
J2
POWER
+24V 24V power supply output terminal
J2 GND 24V power supply output GND terminal
J2
B, C Origin
Switch
B B Origin
J2 C C Origin
J2
Press
IN14 Pressure detection
J2 IN15 Vacuum detection
J2 POWER +24V 24V power supply output terminal
