Adtech CNC9640 User Manual

ADTECH9 Series CNC Maintenance Manual
- 234 -
J38 IN03 IN35 #1035
J38
POWER
+24V 24V power supply output terminal
J38 GND 24V power supply output GND terminal
J38
IN07-IN04
IN04 IN36 #1036
J38 IN05 IN37 #1037
J38 IN06 IN38 #1038
J38 IN07 IN39 #1039
J38
POWER
+24V 24V power supply output terminal
J38 GND 24V power supply output GND terminal
J38
IN11-IN08
IN08 IN40 #1040
J38 IN09 IN41 #1041
J38 IN10 IN42 #1042
J38 IN11 IN43 #1043
J39
POWER
+24V 24V power supply output terminal
J39 GND 24V power supply output GND terminal
J39
IN15-IN12
IN12 IN44 #1044
J39 IN13 IN45 #1045
J39 IN14 IN46 #1046
J39 IN15 IN47 #1047
J39
POWER
+24V 24V power supply output terminal
J39 GND 24V power supply output GND terminal
Terminal
No.
Area Port Name Extended input of Standard system
J39
IN19-IN16
IN16 IN48 #1048
J39 IN17 IN49 #1049
J39
IN18 IN50 #1050
J39 IN19 IN51 #1051
J39
POWER
+24V 24V power supply output terminal
J39 GND 24V power supply output GND terminal
J39
IN23-IN20
IN20 IN52 #1052
J39 IN21 IN53 #1053
J39 IN22 IN54 #1054
J39 IN23 IN55 #1055
