ADTECH9 Series CNC Programming Manual
Arc Interpolation Command Format Description
S/N
Data content
Instruction
Meaning
1
Plane selection
Plane selection
Specify the arc interpolation on X-Y
plane
Specify the arc interpolation on Z-X
plane
Specify the arc interpolation on Y-Z
plane
2
Arc direction
Arc direction
Arc interpolation in clockwise direction
CW
Arc interpolation in counterclockwise
direction CCW
3
End
point
G90 mode
Two axes instruction in
X, Y, Z
The coordinate value of the end point
position in current workpiece
coordinate system
G91 mode
Two axes instruction in
X, Y, Z
Distance from start point to end point
(directional)
4
Distance from start
point to circle center
Distance from start point
to circle center
Two axes instruction in I, J, K
Arc radius
Arc radius
Arc radius
5
Feeding rate
Feeding rate
The speed of arc motion
Details:
G02 (G03) is modal instruction.
The arc crossing multiple quadrants can be specified in one program segment.
Note:
Arc direction
X-Y plane: look to negative direction from Z axis
X-Z plane: look to negative direction from Y axis
Y-Z plane: look to negative direction from X axis
