Adtech CNC9650 Programming Manual

ADTECH9 Series CNC Programming Manual
The feeding speed of arc interpolation is specified with F, which is the speed of tool in arc tangent direction.
2.1.5. Pause instruction (G04)
Function:
Pause for a period of time between two program segments.
Format:
G04 P_ or G04 X_
Address P specifies the pause time, and the minimum unit of its instruction is
0.001 second if there is no radix point.
Address X specifies the pause time, and the minimum unit of its instruction is
1 second if there is no radix point.
 Example:
G04 P 1000 : pause for 1000ms, equal to 1sec
G04 X 1 : pause for 1sec
2.1.6. Plane selection (G17-G19)
Function:
This group of instruction is used to select the plane of arc interpolation and tool radius compensation.
Format:
G17………select XY plane
G18………select ZX plane
G19………select YZ plane
X, Y, Z indicate the coordinate axes or parallel axes
Details:
When the system is electrified, plane XY is selected by default.
In the program segment without instruction G17, G18 or G19, the plane doesn’t have any change.
 Example:
