Table 4.27: ADAM-4080D Command Table
Command Syntax Command Name Command Description Page No.
%AANNTTCCFF Configuration
Sets the address, input mode, baud
rate, checksum status and/or fre-
quency gate time for a specified
counter/ frequency module
7-28
$AA2 Configuration Status
Returns configuration parameters
from the specified counter/frequency
module
7-30
$AAF
Read Firmware
Version
Return firmware version code from
the specified counter/frequency mod-
ule
7-31
$AAM Read Module Name
Return the module name from the
specified counter/frequency module
7-32
$AABS
Set Input Signal
Mode
Sets the input signal mode of the
specified counter/frequency module
to either non-isolated or photo-iso-
lated input signals
7-33
$AAB
Read Input Signal
Mode
Read the input signal mode of the
specified counter/frequency module.
7-34
#AAN
Read Counter or
Frequency Value
Returns the value of counter 0 or
counter 1 from a specified counter/
frequency module in hex format
7-35
$AA8V
Select LED Data
Origin
Select whether LED will display data
from the counter/frequency module
directly or from the host computer
7-36
$AA8
Read LED Data
Origin
Returns the status of the LED Data
origin. Origin is either direct from
module or from host computer
7-37
$AA9(data) Send Data to LED
The host computer sends data to the
addressed module to display on its
LED. This command is valid only after
selecting to display host computer
data ($AA8V)
7-38
$AAAG Set Gate Mode
Requests the specified counter/ fre-
quency module to set its gate mode
to either high, low or disabled
7-40
$AAA Read Gate Mode
Requests the specified counter/
frequency module to return the status
of its gate mode
7-41
$AA3N(data)
Set Maximum
Counter Value
Sets the maximum value of counter
0 or counter 1 for the specified coun-
ter/frequency module
7-42
$AA3N
Read Maximum
Counter Value
Reads the maximum value of counter
0 or counter 1 of the specified coun-
ter/ frequency module
7-43
$AA5NS Start/Stop Counter
The command orders the specified
counter/frequency module to start or
stop counting
7-44
$AA5N
Read Counter
Start/Stop Status
The addressed counter frequency
module returns its status indicating
whether counting is enabled or dis-
abled
7-45
