B.4 Analog Output Ranges
Range Code
(hex)
Input Range
Description
Data Formats
Maximum
Specified
Signal
Minimum
Speciated
Signal
Output
Resolution
30 0 to 20 mA
Engineering
Units
20.000 00.000 5 µA
% of FSR +100.00 +000.00 5 µA
Hexadecimal
Binary
FFF 000 5 µA
31 4 to 20 mA
Engineering
Units
20.000 04.000 5 µA
% of FSR +100.00 +000.00 5 µA
Hexadecimal
Binary
FFF 000 5 µA
32 0 to 10 V
Engineering
Units
10.000 00.000 2.442 mV
% of FSR +100.00 +000.00 2.442 mV
Hexadecimal
Binary
FFF 000 2.442 mV
