299 ADAM-4000 Series User Manual
Appendix A Technical Specifications
A.9 ADAM-4019+ 8-channel Universal Analog Input
Module
Table A.13: ADAM-4019+ Specifications
AI channel number 8
Input type V, mV, mA and T/C
Input range
V: ±1 V , ±2.5 V, ±5 V , ±10 V
mV: ±100 mV , ±500 mV
mA: ±20 mA (with120 resister)
4~20 mA(with 120 resister) Thermocouple:
J 0 to 760 °C
K 0 to 1370 °C
T -100 to 400 °C
E 0 to 1400 °C
R 500 to 1750 °C
S 500 to 1750 °C
B 500 to 1800 °C
Isolation voltage
3000 V
DC
Resolution 16-bit
Sampling rate 10 samples/sec (total)
Input impedance 20 M
Accuracy ±0.1% or better
Zero drift ±6 V/°C
CMR @ 50/60 Hz 120 dB
NMR @ 50/60 Hz 100 dB
Span drift ±25 ppm/°C
Support protocol ADAM ASCII and MODBUS/RTU
Watchdog timer System (1.6 second) and communication
Power requirements
+10 to +30 V
DC
(non-regulated)
Power consumption
1.0 W @ 24 V
DC
Burn-out detection +4~20mA and all Thermocouple input
