315 ADAM-4000 Series User Manual
Appendix A Technical Specifications
A.17 ADAM-4060 Relay Output Module
Table A.21: ADAM-4060 Specifications
DO channel number
4 channel relay
(2 form A, 2 form C)
Input
speed (bps)
Maximum distance
RS-485 (2-wire)
1200, 2400, 4800, 9600, 19.2K, 38.4K, 57.6K, 115.2K
4000 ft. (1200 m)
Contact rating
(Resistive)
AC: 0.6 A @ 125 V
0.3 A @ 250 V
DC: 2 A @ 30 V
0.6 A @ 110 V
Breakdown voltage
500 V
AC
(50/60 Hz)
Relay on time (typical) 3 ms
Relay off time (typical) 2 ms
Total switching time 10 ms
Insulation resistance
1 G minimum at 500 V
DC
Support protocol ADAM ASCII
Watchdog timer 1.6 second (System)
Power supply
+10 to +30 V
DC
(non-regulated)
Power consumption
0.8 W @ 24 V
DC
