37 ADAM-4000 Series User Manual
Chapter 3 I/O Modules
3.5.2 Technical specification of ADAM-4015
Table 3.1: Technical Specification of ADAM-4015
Channel Number 6 differential
Support Protocol ADAM ASCII and MODBUS/RTU
Input Type Pt100, Pt1000, BALCO500, Ni
Input Connections 2 or 3 wires
Wire Burnout Detection Yes
Input Type and Temper-
ature Range
Pt100: -50 to 150° C
0 to 100° C
0 to 200° C
0 to 400° C
-200 to 200° C
Pt1000: -40 to 160° C
Balco500: -30 to 120° C
Ni 50 RTD: -80 to 100° C
Ni 508 RTD: 0 to 100° C
Isolation Voltage 3000 V
DC
Sampling Rate 10 sample/second (total)
Input Impedance 10 M
Resolution 16-bit
Accuracy ±0.1% (Typical)
CMR@50/60Hz 120 dB
NMR@50/60Hz 100 dB
Span Drift ± 25 ppm/°C
Zero Drift ± 3 V/°C
Watchdog Timer System (1.6 second) and Communication
Power Input +10~+30 V
DC
(non-regulated)
Power Consumption 1.2 W @ 24V
DC
ADAM-4015
RTD type Temperature Range Accuracy
Platinum 100 (IEC)
-50 ~ 150°C
0 ~ 100°C
0 ~ 200°C
0 ~ 400°C
-200 ~ 200°C
0.10%
Platinum 100 (JIS)
-50 ~ 150°C
0 ~ 100°C
0 ~ 200°C
0 ~ 400°C
-200 ~ 200°C
0.2% or better
Platinum 1000 -40 ~ 160°C 0.10%
BALCO 500 -30 ~ 120°C 0.50%
Ni 508 -50 ~ 200°C 0.10%
Ni 604
-80 ~ 100°C
0 ~ 100°C
0.10%
