Appendix B Data Formats and I
/
O Ranges
Range Code
(hex)
Input Range
Description
Data Formats
Maximum
Specified
Signal
Minimum
Specified
Signal
Displayed
Resolution
22
100.00 
Platinum RTD
 = .00385
0°C to 200°C
Engineering
Units
+200.00 +000.00 0.01°C
% of FSR +100.00 +000.00 0.01%
Twos
Complement
7FFF 0000 1 LSB*
Ohms +175.84 +100.00 10 m
23
100.00  Platinum
RTD  = .00385
0°C to 600°C
Engineering
Units
+600.00 +000.00 0.01°C
% of FSR +100.00 +000.00 0.01%
Twos
Complement
7FFF 0000 1 LSB*
Ohms +313.59 +100.00 10 m
24
100.00  Platinum
RTD  = .00392
-100°C to 100°C
Engineering
Units
+00.00 -100.00 0.01°C
% of FSR +100.00 +000.00 0.01%
Twos
Complement
7FFF 8000 1 LSB*
Ohms +139.16 +060.60 10 m
25
100.00  Platinum
RTD  = .00392
0°C to 100°C
Engineering
Units
+100.00 +000.00 0.01°C
% of FSR +100.00 +000.00 0.01%
Twos
Complement
7FFF 0000 1 LSB*
Ohms +139.16 +100.00 10 m
26
100.00  Platinum
RTD  = .00392
0°C to 200°C
Engineering
Units
+200.00 +000.00 0.01°C
% of FSR +100.00 +000.00 0.01%
Twos
Complement
7FFF 0000 1 LSB*
Ohms +177.13 +100.00 10 m
27
100.00  Platinum
RTD 
= .00392
0°C to 600°C
Engineering
Units
+600.00 +000.00 0.01°C
% of FSR +100.00 +000.00 0.01%
Twos
Complement
7FFF 0000 1 LSB*
Ohms +317.28 +100.00 10 m
28
120 
Nickel RTD
-80°C to 100°C
Engineering
Unit
+100.000 -80.00 0.01°C
% of FSR +100.00 +000.00 0.01%
Twos
Complement
7FFF 8000 1 LSB*
Ohms +200.64 +066.60 10 m
29
100.00 
Nickel RTD
 = .00392
0°C to 100°C
Engineering
Unit
+100.000 +000.00 0.01°C
% of FSR +100.00 +000.00 0.01%
Twos
Complement
7FFF 0000 1 LSB*
Ohms +200.64 +120.00 10 m
