369 ADAM-4000 Series User Manual
Appendix G I/O Modbus Mapping Table
9. ADAM-4056SO 12 channel Source-type Isolated Digital Output Module
ADDR 0X Channel Item Attribute Memo
00017 0 Digital Output Value R/W
00018 1 Digital Output Value R/W
00019 2 Digital Output Value R/W
00020 3 Digital Output Value R/W
00021 4 Digital Output Value R/W
00022 5 Digital Output Value R/W
00023 6 Digital Output Value R/W
00024 7 Digital Output Value R/W
00025 8 Digital Output Value R/W
00026 9 Digital Output Value R/W
00027 10 Digital Output Value R/W
00028 11 Digital Output Value R/W
00029 Over Current CH0-3 Over Current Flag R/W
00030 Over Current CH4-7 Over Current Flag R/W
00031 Over Current CH8-11 Over Current Flag R/W
ADDR 4X Channel Item Attribute Memo
40211 Module Name 1 R 0x40 0x56
40212 Module Name 2 R 0x53 0x4F
40213 Version 1 R 0xA1 0x00
40214 Version 2 R 0x00 0x00
40215 Comm Safety Enable R Enable:0x00 0x01
40216 Comm Safety Flag R Occur:0x00 0x01
