AIMB-584 User Manual 2
1.1 Introduction
AIMB-584 is designed with the Intel Q87/C226 for industrial applications that require
both performance computing and enhanced power management capabilities. The
motherboard supports Intel Core i7 Xeon E3-1275v3 3.5GHz/ E3-1225v3 3.2GHz/
E3-1268L 2.3GHz/ Core i7-4770 3.1GHz/ Core i5-4570 2.9GHz/ Core i3 4330 3.5
GHz/ Pentium G3420 3.2 GHz/ Celeron G3320TE 2.3 GHz processor up to 8 MB L3
cache and DDR3 1333/1600 up to 32GB up to 16 GB. A rich I/O connectivity of 6
serial ports, 8 USB 2.0, 4 USB 3.0, dual GbE LAN, 6 SATA III ports.
1.2 Features
Rich I/O connectivity: Dual GbE LAN via PCIe x1 bus, 2 x PCI 32- bit/33 MHz
PCI slots, 1 x PCIe x16 slot (Gen 3), 1 x PCIe x4 slot (Gen 2), 8 USB 2.0 ports
and 4 USB 3.0 ports.
Standard Micro ATX form factor with industrial feature: The AIMB-584 is a
full featured Micro ATX motherboard with balanced expandability and perfor-
mance.
Wide selection of storage devices: SATAIII HDD, customers benefit from the
flexibility of using the most suitable storage device for larger capacity.
Optimized integrated graphic solution: With Intel® Flexible Display Interface,
it supports versatile display options and 32-bit 3D graphics engine.
1.3 Specifications
1.3.1 System
CPU: Intel 4th generation Xeon E3 and Core i7/i5/i3 processor
BIOS: AMI EFI 128 Mbit SPI BIOS
System chipset: Intel® Q87/C226
SATA hard disk drive interface: Six on-board SATA connectors with data
transmission rate up to 600 MB
1.3.2 Memory
RAM: Up to 32 GB in 4 slots 240-pin DIMM sockets. Supports dual-channel
DDR3 1333/1600MHz SDRAM.
– AIMB-584QG2 supports non-ECC unbuffered DIMMs and do not support any
memory configuration that mixes non-ECC with ECC unbuffered DIMMs.
– AIMB-584WG2 supports ECC buffered DIMMs.
Note! A 32-bit OS may not fully detected 4GB of RAM when 4 GB is installed.
