11 AIMB-584 User Manual
Chapter 1 General Information
1.10 Memory Installation Procedures
To install DIMMs, first make sure the two handles of the DIMM socket are in the
“open” position, i.e., the handles lean outward. Slowly slide the DIMM module along
the plastic guides on both ends of the socket. Then firmly but gently (avoid pushing
down too hard) press the DIMM module well down into the socket, until you hear a
click when the two handles have automatically locked the memory module into the
correct position of the DIMM socket. To remove the memory module, just push both
handles outward, and the memory module will be ejected by the mechanism.
1.11 Cache Memory
The AIMB-584 supports a CPU with one of the following built-in full speed L3 caches:
8MB for Intel Xeon E3 1275v3
8MB for Intel Xeon E3 1225v3
8MB for Intel Xeon E3 1268L
8MB for Intel Core i7 4770S
8MB for Intel Core i7 4770TE
6MB for Intel Core i5 4570S
4MB for Intel Core i5 4570TE
3MB for Intel Core i3 4330
3MB for Intel Core i3 4330TE
3MB for Intel Pentium G3420
3MB for Intel Celeron G3320TE
The built-in second-level cache in the processor yields much higher performance
than conventional external cache memories.
1.12 Processor Installation
The AIMB-584 is designed for LGA1150, Intel Xeon and Intel Core i7/Core i5/Core i3/
Pentium processor.
1.13 PCI Bus Routing Table
AD PCI slot INT
PCI1 PCI2
AD16 AD17
A A B
B B C
C C D
D D A
