1.3.3 Input/Output
 PCIe slot: 1 PCIe x16 expansion slot, 1 PCIe x4 expansion slot
 PCI Bus: 2 PCI slots, 32-bit/33 MHz PCI 2.2 compliant
 Enhanced parallel port: Configured to LPT1 or disabled. Standard DB-25
female connector cable is a optional accessory. LPT1 supports EPP/SPP/ECP.
 Serial port: Six serial ports, one is RS-232/422/485 with hardware auto-flow
control and four are RS-232. One DB-9 connectors located in rear panel are
RS-232.
 Keyboard and PS/2 mouse connector: Two 6-pin mini-DIN connectors are
located on the mounting bracket for easy connection to PS/2 keyboard and
mouse.
 USB port: Supports up to 8 USB 2.0 ports with transmission rates up to 480
Mbps and 4 USB 3.0 ports with transmission rates up to 5 Gbps.
 GPIO: AIMB-584 supports 8-bit GPIO from super I/O for general purpose con-
trol application.
1.3.4 Graphics
 Controller: Intel® HD Graphics
 Display memory: 1 GB maximum shared memory with 2GB and above system
memory installed
 DVI: Supports DVI up to resolution 1920 x 1200 @ 60Hz refresh rate
 VGA: Supports VGA up to resolution 2048 x 1536 @ 75Hz refresh rate
 LVDS: Supports LVDS up to resolution 1920 x 1200
 Display Port: Support max resolution 3840 x 2160 @60Hz
 eDP: Support max resolution 3840 x 2160 @ 60Hz
 Triple Display: VGA + eDP (or LVDS)+ DP, VGA+eDP(or LVDS)+ DVI,
VGA+DP+DVI
 Dual Display: VGA+eDP (or LVDS), VGA+DVI, eDP(or LVDS)+ DVI, VGA +
DP, DP+ DVI, LVDS+DP
1.3.5 Ethernet LAN
 Supports dual 10/100/1000 Mbps Ethernet port (s) via PCI Express x1 bus
which provides 500 MB/s data transmission rate
 Controller: LAN1: Intel I217LM; LAN2:Intel I211AT
1.3.6 Industrial features
 Watchdog timer: Can generate a system reset. The watchdog timer is pro-
grammable, with each unit equal to one second or one minute (255 levels)
1.3.7 Mechanical and environmental specifications
 Operating temperature: 0 ~ 60° C (32 ~ 140° F, Depending on CPU)
 Storage temperature: -40 ~ 85° C (-40 ~ 185° F)
 Humidity: 5 ~ 95% non-condensing
 Power supply voltage: +3.3 V, +5 V, +12 V, -12 V, 5 Vsb
Note! The default LVDS setting in BIOS is " disable", customer could enable
this function manually, please see detail information in BIOS section.
