AES 7707 - 4 Installation

AES 7707 RF Subscriber 11
Part No. 40-7707 Rev. 3a 10/23/2017
Table 1. Battery Size Requirements
System Configuration
Description
Current (mA)
Battery
Size
(12 V)
7707
7794A (IntelliPro Fire Module)
7711 (8 zone input card)
See Current Consumption under Technical Specifications
on page 8, 7794A Installation and Operation Manual, and
7711 Installation and Operation Manual
12 Ah
7707
7794A (IntelliPro Fire Module)
7712 (8 zone input card - 4 ea.
EOL and 4 ea. reverse polarity)
See Current Consumption under Technical Specifications
on page 8, 7794A Installation and Operation Manual and
7712 Installation and Operation Manual
12 Ah
7707
7794A (IntelliPro Fire Module)
See Current Consumption under Technical Specifications
on page 8 and 7794A Installation and Operation Manual
12 Ah
4. Installation
Warning! Do NOT install the subscriber unit during a lightning storm.
4.1 7707 Installation
Table 2 lists tasks to perform when installing the AES 7707 Subscriber. Use the list to verify that installation tasks
have been identified and completed. Tasks do not have to be performed in the order listed unless specifically
identified.
Important! Verify AES mesh network connectivity for the subscriber before installing the subscriber enclosure.
Table 2. Installation Tasks
Page
Reference
Out of the Box
9
Subscriber Location/Network Connectivity
9
Antenna Selection and Location
9
Antenna Installation
17
Requirements
Environmental
9
Electrical Supply
10
Wiring Specifications
10
Battery Size
10
Enclosure Installation
Water Damage Prevention
13
Mounting the Enclosure
13
Removing the Mainboard
14
Removing the Zone Input Board
14
