AES 7707 RF Subscriber 35
Part No. 40-7707 Rev. 3a 10/23/2017
Press the MENU button to view the next status message. Additional routing table screens may appear
depending on the number of routes available.
Zone Input Configuration
The status of each zone input for a 7711 zone input card is shown. Values are F for Fire, S for Supervised,
or B for Bypass.
Press the MENU button to view the next status message.
Network Connectivity Status
The IP address and IP connection (DHCP or Static Address) are shown:
When no IP network is available, the No LAN IP message appears as shown below:
Press the MENU button to view the next status message.
Battery and AC Power Status
Press the MENU button to view the next status message.
Ground Fault and Battery Charger Status
Press the MENU button to view the next message.
7794A IntelliPro Software Version
If a 7794A IntelliPro is installed in the Subscriber, the software version will appear as shown below, where
X.XXX is the version number:
When no 7794A is present, the display will show None as shown below:
