AES 7707 RF Subscriber 8
Part No. 40-7707 Rev. 3a 10/23/2017
2. Technical Specifications
External Class 2 AC Transformer and
Rechargeable Backup Battery
Transformer Voltage/Frequency: 120 V AC 60 Hz
Input Current: 1.9 A max. current (40 VA min.)
Input Voltage: 16.5 V AC
12 V DC – Lead Acid Gel Cell – 10 to 12 Ah – configuration dependent. See
Table 1– Battery Size Requirements for details.
24 V DC from External Regulated
Power Supply
12 V DC Rechargeable Backup Battery
in Subscriber
UL Listed 24 V DC Regulated Power Supply with 12 V DC Rechargeable
Backup Battery in Subscriber
Input Voltage: 24 V DC
Input Current: 1.9 A Maximum
24 V DC Regulated Power Supply
from FACP AUX Power
Rechargeable Backup Battery in FACP
UL Listed FACP with Rechargeable Backup Battery
Input Voltage: 24 V DC
Input Current: 1.9 A Maximum
7707 – Standby w/o backup battery: 200 mA (1.2 A Transmitting)
7707 – Standby w/ charged backup battery: 200 mA (1.2 A Transmitting)
7707 – Standby + charging backup battery: 900 mA (1.9 A Transmitting – Maximum)
Operating Temperature: 32°F to 120°F (0°C to 49°C)
Storage Temperature: 14°F to 140°F (–10°C to 60°C)
Relative Humidity: 0 to 93% RHC, non-condensing
Dimensions: 13 in. H × 8 ½ in. W × 4 ½ in. D (33 cm × 21.5 cm × 11.4 cm)
Weight: 5.8 pounds (2.6 kilograms) without battery
13 pounds (5.9 kilograms) with 10 Ah battery
Enclosure Material: Steel with paint finish
Finish Color: Red
Alarm Signal Inputs:
7707 + 7711 Input Card (eight (8) each EOL type)
7707 + 7712 Input Card (four (4) each EOL type and four (4) each reverse polarity)
All inputs supervised with trouble and restore
Alarm Panel Phone Line Input:
7794A IntelliPro Fire Module
AC Failure (low primary AC voltage limit: 85 V AC)
Low Battery (low battery voltage limit: 11.6 V DC)
Zone Input Ground Fault (impedance to earth ground is less than 50k ohm)
Antenna Cut
Battery Charger Failure
