AES 7707 - Programming and Configuration; UL Programming Options and Limitations

AES 7707 RF Subscriber 23
Part No. 40-7707 Rev. 3a 10/23/2017
7.4 Trouble Output
 J4 – Trouble Relay Contacts – 24 V DC 1A Max. Resistive Load Unsupervised
 Annunciator – AES Model 7740 Remote Annunciator – 21 V DC 25 mA Typ. (50 mA max.) Supervised.
Refer to the Compatible Device Installation and Field Wiring Connections section on page 19 for
instructions on installing and connecting field wiring on the Model 7740.
8. Programming
8.1 Programming Options (UL Notice to Users)
NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING JURISDICTION, AND
OTHER INVOLVED PARTIES
This product incorporates field-programmable software. In order for the product to comply with the requirements in the
Standard for Control Units and Accessories for Fire Alarm Systems, UL 864, certain programming features or options must be
limited to specific values or not used at all as indicated below.
Table 3. Limitations in Programming Features and Options
Topic
Feature or Option
Permitted
in UL
864/ULC
S559
Possible
Settings
Setting(s)
Permitted in UL
864/ULC S559
Comment
Radio
Secondary Alarm Delay
Y
1‒330 seconds
1‒10 seconds
Check-in Time
Y
0‒24 hours
0‒24 hours
Communication Timeout
Y
1‒300 seconds
1‒60 seconds
Repeating
Y
Y or N
Y
Zone
Configuration
Zone Programming
Y
Supervised,
Fire,
or Bypass
Zone in use: Fire
Zone not in use:
Bypass
Supervised not to be
used in fire
applications.
Fire Zones
Y
Y or N
Y
Only if 7712
or 7711 is
used
Consecutive AT
Events
Y
Y or N
Y
Y for verbose zone
input alarm and
trouble message
reporting. Refer to
Pg. 31 for details.
Restoral
Y
Y or N
Y
Power from 16.5 V AC and
Backup Battery
Y
16.5 V AC and
Backup Battery
Y
Plug in Class 2
transformer with
rechargeable backup
battery in Subscriber
Power
Options
24 V DC Regulated Power
Supply with Backup
Battery
Y
24 V DC and
Battery
Y
UL Listed for Fire Service
Regulated Power Supply
24 V DC or FACP 24 V DC
output. Rechargeable
backup battery in
Subscriber.
