3. Pre-Installation
3.1 Equipment List
The following materials are available out of the box:
Enclosure with key lock and two keys
7707 Subscriber Main Circuit Board Assembly
7085UE or 7880 2-Watt Transceiver set to authorized frequency
7214 Case Top Flexible Tamper Resistant Antenna with cable assembly
40-7707-QSG Model 7707 Quick Start Guide
02-0029-EOL 2.2 kΩ E.O.L. Resistors (quantity is variable depending on zone input card(s) supplied)
Configuration dependent:
7711 8 Zone EOL Input Card
7712 4 Zone EOL and 4 Zone Reverse Polarity Input Card
7794A IntelliPro Fire Module
3.2 Mounting
Subscriber Location
Important! A fire alarm installation that complies with UL 864 or ULC-S559 using the 7707 Subscriber must be
located where a NetCon of 5 is present. Refer to Link Layer and NetCon on page 34 for additional details on how to
view NetCon. It is important to verify that a location is suitable before deciding on the antenna used and mounting
the subscriber enclosure. A check of the location can be done with the AES Network Connectivity Tool (NCT). The
AES NCT provides a quick means for verifying NetCon or finding suitable locations for Subscriber installation.
Antenna Selection and Location
The Case Top Flex Tamper Resistant Antenna is part of the standard package for the 7707 System and mounts on
top of the steel cabinet.
Depending on cabinet mounting, Subscriber physical location, and mesh network connectivity, a remote mount
antenna may be required.
A separately purchased remote antenna may be used with the 7707 unit in UL installations. See External Antenna
on page 17 for information on antennas available from AES. The frequency range is 450–470 MHz. Contact the
factory at (800) 237-6387 or info@aes-corp.com for other frequencies.
3.3 Requirements
Environmental
Select an installation location that meets the Environmental Specifications described in the Technical Specifications
section on page 8.
