The grid of the radiographic table is removed or inserted
wrongly.
The grid of the radiographic wall stand is inserted.
The grid of the radiographic wall stand is removed or inserted
wrongly.
The grid of the radiographic table is inserted.
The grids are both removed or inserted wrongly.
Table 29: Size and orientation of the DR detector in the radiographic table
The bucky contains a DR detector with a size of 14x17 inch
(35x43 cm) in landscape orientation.
The bucky contains a DR detector with a size of 14x17 inch
(35x43 cm) in portrait orientation.
The bucky contains a DR detector with a size of 17x17 inch
(43x43) cm)
The bucky is empty.
Table 30: Size and orientation of the DR detector in the radiographic wall
stand
The bucky contains a DR detector with a size of 14x17 inch
(35x43 cm) in landscape orientation and positioned in the cen-
ter.
Valory (system with floor mounted column) | Tube head display | 127
0426A EN 20220804 1858
