AGFA Valory - Radiographic Table Technical Data

Radiographic Table Technical Data
Manufacturer
DK Medical Systems Co., LTD
52, ChupalSandan1-gil, Paengseong-eup,
Pyeongtaek–si, Gyeonggi-do, Korea, 17998
Type
TE-90A
TF-90A
Dimensions
Radiographic table
TE-90A: 2206 mm x 800 mm x 530-820 mm
(WxDxH)
TF-90A: 2206 mm x 800 mm x 700 mm
(WxDxH)
Tabletop 2206 mm x 800 mm (WxD)
Tabletop movement
Longitudinal, left and right 414 mm
Transversal, back and front 150 mm
Bucky movement range 510 mm
Distance between tabletop
and detector
≤ 81 mm
Tabletop attenuation equiva-
lent mm Aluminum
≤ 1 mm
A tabletop with attenuation < 0.7 mm is
available as an option.
Weight of the radiographic
table (including tabletop)
TE-90A: 215 kg
TF-90A: 197 kg
Maximum load on the radio-
graphic table
320 kg in the center of the table
100 kg at the end of the table
