Unloading of the bucky in the table
To unload the bucky with a detector:
1. Open the bucky drawer completely by pulling the front handle.
2. Unlock the clamps by turning the lock lever counterclockwise.
Figure 86: Unlock icon
3. Open the clamps.
4. Lift the detector and remove it from the clamping. The openings in the
carrier allow your fingers to grip the detector.
5. Load the bucky with another detector.
• Alternatively, close the bucky drawer using the front handle and
pushing the button to release the brake.
154 | Valory (system with floor mounted column) | Bucky
0426A EN 20220804 1858
