Positioning the X-Ray Tube
The operation controls of the X-ray tube head unit are located at the control
panel. The X-ray tube can be positioned by the operator manually.
To release the brake for the selected movement direction or rotation, press
and hold the button and move the X-ray tube head unit.
To stop the movement and activate the brake, release the button.
Note: If movement in any direction blocks, do not apply force to
overcome the blocking. Contact your local service organization.
Note: To avoid shock and damage, move the tube head unit with
normal speed and slow down when reaching the mechanical end
stops.
Note: Rotation may be limited by cables. Avoid strain on the cables
during rotation.
Related Links
X-ray tube head unit on page 20
Topics:
• Stop positions
• Centering the tube head on the table
• Centering the tube head on the wall stand
Valory (system with floor mounted column) | Positioning the X-Ray Tube | 129
0426A EN 20220804 1858
