1.
Bucky drawer
2.
Clamps
3.
Lock lever
4.
Bucky drawer handle
5.
Anti-scatter grid handle
6.
Detachable clamp
7.
Slit for attaching the detachable clamp
Figure 80: Bucky in the radiographic wall stand
When the detachable clamp is not used, it can be stored by attaching it
magnetically at the rear side of the wall stand bucky.
Figure 81: Storing the detachable clamp
Topics:
• Loading of the bucky in the table
• Loading of the bucky in the wall stand
• Unloading of the bucky in the table
• Unloading of the bucky in the wall stand
Valory (system with floor mounted column) | Bucky | 149
0426A EN 20220804 1858
