Release the brake for movement in vertical direction (up & down).
6.
Figure 9: Longitudinal movement button
Release the brake for movement in longitudinal direction (left & right).
There are stop positions for default SID on the radiographic wall stand.
7.
Figure 10: Tilting button
Release the brake for tilting of the X-ray tube (alpha rotation).
8.
Figure 11: Transversal movement button
Release the brake for movement in transversal direction (back & forth).
There are stop positions for centering on the radiographic table and on the
radiographic wall stand.
9.
Figure 12: Omni-direction movement button
Release the brake for movement in transversal, vertical and longitudinal
direction.
Figure 5: X-ray tube head unit
Related Links
Positioning the X-Ray Tube on page 129
