Agilent Technologies 1290 - Operating Principle

1290 Infinity Quaternary Pump User Manual 13
Introduction
1
Operating Principle
Figure 1 The hydraulic path
Pump head
Inline filter
Jet Weaver (optional)
Pressure sensor
Solvent bottles
Degasser
Multi-channel gradient valve
Inlet weaver
Multi Purpose Valve
